This 3.5mm Pitch 2 Pin 2 Way Straight Pin PCB Screw Terminal Block Connector is designed for secure and reliable connections in various electronic applications. Moulded in green UL94-V0 flame retardant PA, it provides enhanced durability and safety. The connector features a double interlocking mechanism that ensures increased strength and a guided pin alignment for easy and accurate installation. The captived screws offer added convenience by preventing loss during installation or maintenance. With its robust design and secure locking features, this terminal block connector is ideal for applications requiring strong, reliable electrical connections.
Connectors, Electronic Components, Terminal Blocks, Wire-To-Board Terminal Blocks
2 pin Straight PCB Screw Terminal Block Connector-3.5mm Pitch
- Pitch: 3.5 mm
- Poles: 2 Pin
- Rated voltage: 300 V
- Rated current: 10 A
- Withstand length: 4.5~5 mm
- Withstanding voltage: AC 1500V/1Min
₹10.00
Wishlist| Manufacturer: | Generic |
|---|---|
| Pitch Spacing (mm): | 3.5 |
| No. of Pins: | 2 |
| Rated Voltage (V): | 300 V |
| Current Rating (A): | 10 |
| Contact Resistance | 20mΩ MAX |
| Allowed Wire Size (AWG): | 18 to 24 |
| Operating Temperature (°C): | -40 °C ~ +105 °C |
| Torque: | 0.2Nm(1.8lb.in) |
| Shipping Weight | 0.001 kg |
| Shipping Dimensions | 1 × 1 × 1 cm |
